CURT Custom Wiring Connector #55378

$85.02

Add to Wishlist Browse Wishlist
SKU: 612314553785 Category:

Description

A CURT custom wiring connector (sometimes called a T-connector) is a simple, plug-and-play electrical device that eliminates the need for cutting, splicing and soldering when installing vehicle-to-trailer wiring.

Most vehicles do not come ready to tow. Unless your vehicle has a towing package, it is probably not equipped with a trailer wiring connector. This is where CURT’s custom wiring connectors come into play. A custom wiring connector uses a single original equipment plug to plug into a special socket provided by your vehicle. Though this option is not available on every vehicle, some automotive manufacturers design their vehicles to be easily equipped for towing by supplying a socket, integrated into the vehicle’s electrical system, to readily accept a custom wiring connector. With a CURT custom wiring connector, there is no need to tap into the taillight assembly because a special socket is already provided.

This custom wiring connector provides a 4-way flat connector socket and comes with a circuit-protected converter. It is designed to be a custom wiring option for certain years of the Toyota Tundra with tommy gate lift (excludes towable bumper models) (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). CURT custom wiring connectors are designed to be long-lasting and simple to install. They come with dust covers to keep your connector clean when not in use and feature a one-year limited warranty to give you peace of mind.

Details

T-Connector Location: T3
Warranty: One Year Limited
Product Type Description: Custom Wiring Connector
Battery-Powered: Yes
Shipping Weight: 0.975
Turn and Brake Circuits: 3.0 Amps
Tail Light Circuits: 6.0 Amps
Electrical System Type: 3W
Output Type: 4-Way Flat
Converter Type: Circuit Protected and Powered

Notes

  • Plugs into existing OEM vehicle socket to provide a 4-way flat socket
  • Simple plug-and-play design eliminates the need for cutting or splicing
  • 4-way flat output connects tail lights, brake lights and turn signals
  • Equipped with a 3-wire to 2-wire tail light converter
  • Constructed with SMT circuitry for better performance and durability
  • Dust cover included to keep connector clean when not in use
  • Slit loom keeps wires contained and well protected
  • Backed by a limited one-year warranty
  • Made in USA

Additional

  • Includes powered 3-wire to 2-wire electrical converter with wiring kit (connection to battery required)

Installation

Instruction sheet: PDF Download
